Page #7 background imageLoading...
Page #7 background image
7
REPLACEMENT PARTS LIST
1 Retaining Ring 20 2
2 Washer 20 2
3 Front Wheel 2
4 Frame 1
5 Rear Caster Assembly 2
6 Screw 12X22 4
7 Washer 12 4
8 Washer 16 2
9 Screw 4X15 4
10 Nut M16 2
11 Washer 18 2
12 Handle Yoke Bolt 2
13 Handle, Lower Section 1
14 Screw 6X32 1
15 Handle, Upper Section 1
16 Handle Set Screw 1
17 Handle Yoke 1
18 U-Joint 1
19 Hydraulic Power Unit 1
20 Return Spring 2
21 Cover Plate 1
22 Retaining Ring 25 2
23 Pin A4X55 1
24 Hydraulic Power Unit Adaptor 1
25 Zerk 1
26 Lift Arm Assembly 1
27 Saddle 1
28 Saddle Screw 1
29 Tie Rod 2
30 Washer 8 4
31 Screw M8X20 4
32 Rubber Bumper 2
33 Lift Arm Shaft 1
34 Screw 2
35 Radius Linkage 2
36 Retaining Ring 16 2
# Description Quantity
