7
*Included in Repair Kit, item number W1632CK
1 W1632-1 Hydraulic Unit Body 1
2 W1632-2 6 mm Steel Ball* 3
3 W1632-3 Release Valve O-Ring* 1
4 W1632-4 Release Valve* 1
5 W1632-5 Flat Washer* 1
6 W1632-6 Pump Cylinder 1
7 W1632-7 Pump Piston O-Ring* 1
8 W1632-8 Pump Piston Back-up Ring* 1
9 W1632-9 Pump Piston* 1
10 W1632-10 Handle Socket Assembly 1
11 W1632-11 Filter Screen* 1
12 W1632-12 Cylinder Seal* 1
13 W1632-13 Cylinder 1
14 W1632-14 O-Ring* 1
15 W1632-15 O-Ring Retainer* 1
16 W1632-16 Ram Assy. w/Ext. Screw 1
17 W1632-17 Reservoir 1
18 W1632-18 Oil Filler Plug* 1
19 W1632-19 O-Ring* 1
20 W1632-20 Top Nut 1
21 W1632-21 Pump Handle Set 1 Set
# Part # Description Quantity
REPLACEMENT PARTS LIST
