SPECIFICATIONS
Rating 120 V 60Hz
Motor 15 A
No-load Speed 5,000 RPM
Saw Blade 10” (25.4 cm), (40-tooth)
Arbor Size 5/8" (15.9 mm)
Dual laser 635 nm, 1 mW, Class II
Base width 445 mm
Weight 27 lb 14 oz (12.63 KG)
Cutting Capacity
Cross cut 2 x 6” or 4 x 4” (5 × 15 cm or 10 × 10 cm)
Miter cut at 45°, 0° bevel 2 3/8 × 3 3/4” (6 × 9.5 cm)
Crosscut Bevel at 45°, 0° Miter 2 × 6” (5 × 15 cm)
Compound cut at miter 45°,
and bevel 45°
1 1/2” × 3 3/4” (3.8 × 9.5 cm)
OVERVIEW
Laser On/Off Switch: Press the laser switch
to turn the dual laser lines on and off.
Worklight On/Off Switch: Press the
worklight switch to turn the worklight on
and off.
On/Off trigger switch and safety lock-off
button: Press the Lock-off button to
disengage the lock, and then pull the ON/
OFF trigger switch to turn the saw on.
Miter-angle scale: marked in 1° increments,
from 0° to 50° left and 55° right. Positive miter
stops are positioned at 0°, 15°, 22.5°, 31.6°,
and 45° for exact cuts at these common
angles.
Bevel-angle scale: marked in 1° increments
from 0° to 48° left, with 30° marked. Positive
bevel stops are positioned at 0°, 33.9°, 45˚
and 48˚ for exact cuts at these common
bevels.
Miter locking knob: locks knob locks the
saw table at the desired miter angle,
0° to 50° left or 55° right.
Miter-detent Locking lever: locks or
releases the table from a miter detent.
Bevel Locking lever: securely locks your
compound miter saw at the desired bevel
angle.
NOTICE: It is necessary to specially adjust
the 48° left and right bevel angle.
Miter Fence: Hold the workpiece securely
against the miter fence when making all
cuts. Use the hold-down clamp to secure
the workpiece whenever possible.
Self-Retracting Lower Blade Guard: made
of shock-resistant, translucent plastic,
provides protection from each side of the
blade. It retracts over the upper blade guard
as the blade is lowered into the workpiece.
Hold-down Clamp: may be on left or
right fence or base to securely clamp the
workpiece.
Carrying Handle/ support bracket: For
carrying and transporting the saw.
