Page 30
OPERATION
NOTICE: Always use the hold-down
clamp, and place tape on the area being
clamped to avoid marks on the workpiece.
Your miter saw is ideal for cutting crown
molding. To t properly, crown molding
must be compound-mitered with extreme
accuracy. To t at against the ceiling and
the wall, the sum of the angles of the crown
molding’s two connecting surfaces must
equal 90°.
When setting the bevel and miter angles for
compound miter cuts, remember that the
settings are interdependent; changing one
changes the other, as well.
Keep in mind that, because it is very easy for
the angles of crown molding to shift slightly,
all settings should be tested on scrap
molding. Also, most walls do not have
angles of precisely 90°, and therefore, you
will need to ne-tune your settings.
Key Miter Setting Bevel Setting Type of cut
IL 31.6° Right 33.9°
Inside corner - Left side
1. Position top of the molding against the fence.
2. LEFT side is nished piece.
IR 31.6° Left 33.9°
Inside corner - Right side
1. Position bottom of the molding against the fence.
2. RIGHT side is nished piece.
OL 31.6° Right 33.9°
Outside corner - Left side
1. Position bottom of molding against the fence.
2. LEFT side is nished piece.
OR 31.6° Left 33.9°
Outside corner - Right side
1. Position top of molding against the fence.
2. RIGHT side is nished piece.
When cutting crown molding, the bevel
angle should be set at 33.9°, and the miter
angle should be set at 31.6° either left or
right, depending on the desired cut for the
application. See the following table for
correct angle setting and correct positioning
of the crown molding on the miter table.
