Assembly and adjustments
Carefully unpack the router table and all of its parts. Compare the parts against the list below. Do
not discard the carton or any packaging until the router table is completely assembled.
WARNING: If a part is missing or damaged, do not plug in the router table until you
have replaced the missing or damaged part.
1 Table top 16 Carriage bolts (1 large, 1 med, 4 small)
2 Table legs (3) 17 Flat washers for carriage bolts (6)
3 Power switch leg (1) 18 Lock knobs (2 large, 4 small)
4 Fence panels (2) 19 Socket head screws (16)
5 Fence (partially assembled) 20 Locking washers (16)
6 Switch box 21 Flat washers (16)
7 Guard 22 Screws (2)
8 Miter gauge 23 Machine screws (4)
9 Miter bar knob 24 Hex wrench (5 mm)
10 Miter bar 25 Router wrench
11 Table insert 1-1/4” (32 mm) 26 Router
12 Table insert 1-7/8” (47 mm) 27 Router dust collecting attachment*
13 Table insert 2 1/8” (55 mm) *Do not use when the router is installed
14 Starting pin on the router table.
15 Guard pin
10
