MULTIPROP System
Instructions for Assembly and Use – Standard Configuration
B3 Tables and Towers
Moving along with pole
In order to bring the slab table into the
exact position, the PERI MULTIPROP
Table can be moved by means of an
reinforcing bar and a pole.
Moving
1. Insert reinforcing bar (16) into the
bottom bores of the MULTIPROP
Props.
2. Move the slab table with the
reinforcing bar or poles (17).
(Fig. B3.02)
Fig. B3.02
17
16
