Dimension specifications
Dimensions are usually given in mm.
Other units of measure, e.g. cm, are
shown in the illustrations.
Conventions
Instructions are numbered with:
1. ..... , 2. ...... , 3. .....
The result of an instruction is shown
by: J
Position numbers are clearly provided
for the individual components and are
given in the drawing, e.g. 1, in the
text in brackets, for example, (1).
Multiple position numbers, i.e. alter-
native components, are represented
with a slash, e.g. 1 / 2.
SB Brace Frame for single-sided walls
Instructions for Assembly and Use – Standard Configuration
Overview
Key
Presentational reference
The illustration on the front cover of
these instructions is understood to be a
system representation only. The assem-
bly steps presented in these Instruc-
tions for Assembly and Use are shown
in the form of examples with only one
component size. They are valid accord-
ingly for all component sizes contained
in the standard configuration.
For a better understanding, detailed il-
lustrations are partly incomplete. The
safety installations which have possibly
not been featured in these detailed
drawings must nevertheless be availa-
ble.
Arrows
B1 SB -A0, A, B, C
B3 Bracing
C1 SB-1, SB-2
D1 SB-L
20.1 SB-A0
20.2 SB-A
20.3 SB-B
20.4 SB-C
54 SB-L with Anchor Bracket
58 SB-L VARIOKIT
Pictogram | Definition
Safety instructions
Note
Load-bearing point
Visual check
Tip
Arrow representing an action
Arrow representing a reaction of an action*
Forces
* if not identical to the action arrow
