Number of Switch Inputs
This number is the total number of switches that will
be used. The switches can be individual switches or a
multiple rotary switch.
Table 7
Range Default
0 to 2 0
Mode Selection Number
This parameter is a non-programmable parameter
that represents the number of possible combinations
of switch positions. This parameter is based on the
value that is programmed into the “Number of Switch
Inputs” parameter.
Mode Selection Switch Input 2 and
Mode Selection Switch Input 1
The number of these non-programmable parameters
that are visible depends on the value that is
programmed into the “Number of Switch Inputs”
parameter. “Open” signifies that the switch is in the
OFF position. “Ground” signifies that the switch is in
the ON position.
Enabled
If “Yes” is selected, the ECM is programmed to use
the values in “Rating Number” , “Throttle 1 Droop
Percentage” , “Throttle 2 Droop Percentage” and
“TSC1 Droop Percentage” for the given combination
of switch positions.
Table 8
Values Default Factory Password
Yes
No
No Yes
Rating Number
This parameter is the engine rating that is used by the
Electronic Control Module (ECM) for a given
combination of switch positions. There is a maximum
of four ratings in a flash file.
Table 9
Range Default Factory
Password
1 to the maximum
number of ratings in
the currently installed
Flash File
1 No
Rated Speed (RPM)
This parameter represents the engine speed that is
selected when the mode switch or the mode switches
are in a particular position.
Table 10
Range Default Factory
Password
“Programmed Low
Idle” to “Pro-
grammed High Idle”
5.0% No
Throttle 1 Droop Percentage
This parameter represents the amount of droop that
is applied to the “Throttle 1” input.
Table 11
Range Default Factory
Password
0 to 10 percent 5.0% No
Throttle 2 Droop Percentage
This parameter represents the amount of droop that
is applied to the “Throttle 2” input.
Table 12
Range Default Factory
Password
0 to 10 percent 5.0% No
TSC1 Droop Percentage
This parameter represents the amount of droop that
is applied to the “Torque Speed Control 1(TSC1)”
input.
Table 13
Range Default Factory
Password
0 to 10 percent 5.0% No
i05228752
Throttle Setup
The engine can have a digital throttle that uses a
Pulse Width
Modulated (PWM) signal, an analog
throttle, or a multi-position switched throttle. The
Electronic Control Module (ECM) must be
programmed for the type of throttle input that is being
used.
Table 14
Throttle 1 Throttle 2
PWM (Digital Throttle) Analog Throttle
PWM (Digital Throttle) None
PWM (Digital Throttle) Multi-position Throttle Switch
(continued)
30 UENR0678
Programming Parameters
