Illustration 44 g03421140
Typical example
(12) Wastegate Regulator
(13) Inlet Pressure Sensor for the NOx
Reduction System (NRS)
(14) Control Valve for the NRS
(15) Temperature Sensor for the NRS
(16) Differential Pressure Sensor for the
NRS
Illustration 45 g03421147
Typical example
(17) Alternator
(18) Starter Solenoid
(19) Starting Motor
(20) Starter Relay
(21) Low Oil Level Switch (if Equipped)
58
SEBU9063-07
Operation Section
Sensors and Electrical Components
