Maintenance Section
Refill Capacities
Refill Capacities
Lubrication System
The refill capacities for the engine crankcase reflect
the approximate capacity of the crankcase or sump
plus standard oil filters. Auxiliary oil filter systems will
require additional oil. Refer to the Original Equipment
Manufacture (OEM) specifications for the capacity of
the auxiliary oil filter. Refer to the Operation and
Maintenance Manual, “Maintenance Section” for
more information on Lubricant Specifications.
Table 14
Engine
Refill Capacities
Compartment or System
Minimum
(1)
Maximum
(2)
Crankcase Oil Sump
6 L
(1.58 US gal)
14 L
(3.69 US gal)
(1)
The minimum value is the approximate capacity for the crank-
case oil sump (aluminum) which includes the standard factory
installed oil filters. Engines with auxiliary oil filters will require
additional oil. Refer to the OEM specifications for the capacity
of the auxiliary oil filter. The design of the oil pan can change
the oil capacity of the oil pan.
(2)
Approximate capacity of the largest crankcase oil sump. Refer
to OEM for more information.
Cooling System
Refer to the OEM specifications for the External
System capacity. This capacity information will be
needed in order to determine the amount of coolant/
antifreeze that is required for the Total Cooling
System.
Table 15
Engine
Refill Capacities
Compartment or System Liters
Engine Engine
Engine Only TA
(1)
TTA
(2)
9 L (2.37 US gal) 9.4 L (2.48 US gal)
External System Per OEM
(3)
(1)
Single Turbocharger
(2)
Series Turbochargers
(3)
The External System includes a radiator or an expansion tank with the following components: heat exchanger and piping. Refer to the OEM
specifications. Enter the value for the capacity of the External System in this row.
82
SEBU9063-07
Maintenance Section
Refill Capacities
