g01094203
i03976148
Illustration 25
Serial number plate
Plate Locations and Film
Locations
(Engine Aftertreatment System)
Illustration 26 g02151573
Typical example
The module arrangement exhaust plate is installed
on the mounting plate (1). The location of the
arrangement plate mounting plate can alter
depending on the application.
SEBU8601-04
29
Product Information Section
Plate Locations and Film Locations
