Perkins 1206E-E70TTA - Page 48

Table 3
CDL Code
Description
J1939 Code Flash Code
N/A
No Diagnostic Code Detected
N/A 551
1-2
Cylinder #1 Injector data incorrect
651-2
1111-5
Cylinder #1 Injector current below normal
651-5
1-6
Cylinder #1 Injector current above normal
651-6
2-2
Cylinder #2 Injector data incorrect
652-2
1122-5
Cylinder #2 Injector current below normal
652-5
2-6
Cylinder #2 Injector current above normal
652-6
3-2
Cylinder #3 Injector data incorrect
653-2
1133-5
Cylinder #3 Injector current below normal
653-5
3-6
Cylinder #3 Injector current above normal
653-6
4-2
Cylinder #4 Injector data incorrect
654-2
1144-5
Cylinder #4 Injector current below normal
654-5
4-6
Cylinder #4 Injector current above normal
654-6
5-2
Cylinder #5 Injector data incorrect
655-2
1155-5
Cylinder #5 Injector current below normal
655-5
5-6
Cylinder #5 Injector current above normal
655-6
6-2
Cylinder #6 Injector data incorrect
656-2
1166-5
Cylinder #6 Injector current below normal
656-5
6-6
Cylinder #6 Injector current above normal
656-6
18-5 Fuel Control Valve current below normal 1076-5
-
18-6 Fuel Control Valve current above normal 1076-6
-
41-3
8 Volt DC Supply voltage above normal
678-3
517
41-4
8 Volt DC Supply voltage below normal
678-4
91-2
Throttle Position Sensor erratic, intermittent, or incorrect
91-2
154
91-3
Throttle Position Sensor voltage above normal
91-3
91-4
Throttle Position Sensor voltage below normal
91-4
91-8
Throttle Position Sensor abnormal frequency, pulse width, or period
91-08
100-3
Engine Oil Pressure Sensor voltage above normal
100-3
157100-4
Engine Oil Pressure Sensor voltage below normal
100-4
100-21
Engine Oil Pressure Sensor data drifted low
100-21
110-3
Engine Coolant Temperature Sensor voltage above normal
110-3
168
110-4
Engine Coolant Temperature Sensor voltage below normal
110-4
168-2
Electrical System Voltage erratic, intermittent, or incorrect
168-2
511168-3
Electrical System Voltage voltage above normal
168-3
168-4
Electrical System Voltage voltage Below normal
168-4
(continued)
48
SEBU8601-04
Operation Section
Diagnostic Flash Code Retrieval
