(Table 3, contd)
CDL Code
Description
J1939 Code Flash Code
172-3
Intake Manifold Air Temperature Sensor voltage above normal
105-3
133
172-4
Intake Manifold Air Temperature Sensor voltage below normal
105-4
174-3
Fuel Temperature Sensor voltage above normal
174-3
165
174-4
Fuel Temperature Sensor voltage below normal
174-4
190-8
Engine Speed Sensor abnormal frequency, pulse width, or period
190-8 141
247-9
SAE J1939 Data Link abnormal update rate
-
514
253-2
Personality Module erratic, intermittent, or incorrect
631-2 415
261-11
Engine Timing Offset fault
637-11 143
262-3
5 Volt Sensor DC Power Supply voltage above normal
3509-3
516
262-4
5 Volt Sensor DC Power Supply voltage below normal
3509-4
268-2
Programmed Parameter Fault erratic, intermittent, or incorrect
630-2 527
274-3
Atmospheric Pressure Sensor voltage above normal
108-3
152
274-4
Atmospheric Pressure Sensor voltage below normal
108-4
274-13
Atmospheric Pressure Sensor calibration required
108-13
274-21
Atmospheric Pressure Sensor data drifted low
108-21
342-8
Secondary Engine Speed Sensor abnormal frequency, pulse width, or period
723-8 142
526-5
Turbo Wastegate Drive current below normal
1188-5
177
526-6
Turbo Wastegate Drive current above normal
1188-6
535-3
Exhaust Temperature Sensor voltage above normal
3241-3
185
535-4
Exhaust Temperature Sensor voltage below normal
3241-4
774-2
Secondary Throttle Position Sensor erratic, intermittent, or incorrect
29-2
155
774-3
Secondary Throttle Position Sensor voltage above normal
29-3
774-4
Secondary Throttle Position Sensor voltage below normal
29-4
774-8
Secondary Throttle Position Sensor abnormal frequency, pulse width, or period
29-8
993-2
DPF Active Regeneration Inhibited Due to Inhibit Switch
3703-31
-
1262-2
Engine Throttle Actuator 1 Control Command not responding properly
3464-7
-
1634-2
Idle Validation Switch #1 erratic, intermittent or incorrect
558-2 245
1635-2
Idle Validation Switch #2 erratic, intermittent or incorrect
2970-2
246
1639-9
Machine Security System Module abnormal update rate
1196-9
1743-2
Engine Operation Mode Selector Switch erratic, intermittent, or incorrect
2882-2 144
1785-3
Intake Manifold Pressure Sensor voltage above normal
3563-3
197
1785-4
Intake Manifold Pressure Sensor voltage below normal
3563-4
1785-13
Intake Manifold Pressure Sensor calibration required
3563-13
1785-21 Intake Manifold Pressure Sensor data drifted low 3563-21
1797-3
Fuel Rail Pressure Sensor voltage above normal
157-3 159
(continued)
SEBU8601-04
49
Operation Section
Diagnostic Flash Code Retrieval
