Illustration 14 g06135026
Typical example
(10) Rear lifting eye
(11) Turbocharger
(12) Front lifting eye
(13) Water temperature regulator housing
(Thermostat housing)
(14) Coolant pump
(15) Oil cooler
(16) ECM for aftertreatment
(17) Primary fuel filter/priming pump
(18) Oil filter
(19) Oil sample valve
(20) Oil drain plug
(21) Flywheel
(22) Exhaust cooler
M0076814-03 19
Product Information Section
Model View Illustrations
