Engine Lifting
Illustration 26 g06129841
Typical example
(1) Engine lifting eyes
Engines with a factory-mounted CEM and radiator (or
combination thereof) can be lifted by the engine lifting
eyes using a certified spreader bar, assuming a less
than 5 degree tilt angle can be maintained. For most
packages,Perkins recommended the spreader bar be
set at 142 cm (56 inch). The lift hook locations
should be approximately 25 mm (1 inch) from
spreader bar stop toward the front of the engine.
M0076814-03 27
Operation Section
Product Lifting
