The service indicator may need to be replaced
frequently in environments that are severely dusty.
i07819526
Engine Air Precleaner - Check/
Clean
Illustration 73 g01453058
Typical engine air precleaner
(1) Wing nut
(2) Cover
(3) Body
Remove wing nut (1) and cover (2). Check for an
accumulation of dirt and debris in body (3). Clean the
body, if necessary.
After cleaning the precleaner, install cover (2) and
wing nut (1).
Note: When the engine is operated in dusty
conditions, more frequent cleaning is required.
Do not tap or strike the air cleaner element.
i07819538
Engine Mounts - Inspect
Note: The engine mounts may not have been
supplied by Perkins. Refer to the Original Equipment
Manufacturer (OEM) information for further details on
the engine mounts and the correct bolt torque.
Inspect the engine mounts for deterioration and for
correct bolt torque. Excessive engine vibration can
be caused by the following conditions:
• Incorrect mounting of the engine
• Deterioration of the engine mounts
• Loose engine mounts
Any engine mount that shows deterioration should be
replaced. Refer to the OEM information for the
recommended torques.
When the engine mounts are supplied by Perkins the
maintenance procedure will be supplied in the
Disassembly and Assembly manual for your engine.
i08055063
Engine Oil Level - Check
Hot oil and hot components can cause personal
injury. Do not allow hot oil or hot components to
contact the skin.
NOTICE
Perform this maintenance with the engine stopped.
Note: Ensure that the engine is either level or that
the engine is in the normal operating position to
obtain a true level indication.
NOTICE
Do not overfill the crankcase. Engine damage can
result.
Before Operating the Engine
Illustration 74 g06525971
Typical example of type 2 oil level gauge (dipstick)
(L) Low
(H) High
(A) Crosshatched area
(B) Warning symbol
118 M0092609-05
Maintenance Section
Engine Air Precleaner - Check/Clean
