Illustration 79 g06511911
Typical example of an engine oil pan with a balancer
1. Place a suitable container below oil drain plug (1)
and oil drain plug (5).
2. Remove oil drain plug (1) and oil drain plug (5)
from engine oil pan (3) and allow the oil to drain
into the container for storage or disposal.
3. Remove drain plug seal (2) and drain plug seal (4).
Discard the seals.
4. Clean the oil drain plugs and install new drain plug
seal (2) and new drain plug seal (4). Install oil
drain plug (1) and oil drain plug (5) into oil pan (3).
122 M0092609-05
Maintenance Section
Engine Oil and Filter - Change
