IDS-710 Hardware Installation Guide
Appendix A - Technical Specifications
This appendix provides the technical specification for the IDS-710(-XT) switches.
Technical Specification
Power
Power Connector • 8-Pin Removable Terminal Block (4 pins are used
for power 1 and Power 2)
• Grounding screw on metal chassis
• Dual Power Input
Dual Power Input • 12/24/48 VDC nominal
• 9.6-60 VDC range, 0.8A Max.
Alarm Relay • NO (Normally Open)
• 1.0A @ 24VDC or 0.3A @ 48VDC (Resistive)
• Requires Class 2/LPS or SELV circuit with Fuse
protection
Digital Input • IEC 61131-2 Type 3 Digital
• Input
• 24V, 2.25 mA
Rated Cable Temperatures
IDS-710
IDS-710-XT
>98° C
>106° C
Overload Current
Protection
Fuse
Reverse polarity protection Yes
Interfaces
RJ45 Ports • 8 - shielded RJ45
• Up to 100 meters (328 ft.)
• Auto-negotiation
• Auto-MDI/MDIX
Ethernet isolation 1500 V
