Adjustments
Loosen 2 bolts [S1] Level the TV Tighten 2 bolts [S1]
T
Tilt Adjustment
Level Adjustment
1. Loosen four tilt nuts [T] using socket wrench.
2. Adjust TV to your desired tilt angle.
3. Retighten four tilt nuts [T] using socket wrench to fix the tilt angle.
3/8 in.(10mm)
Socket Wrench
1. Loosen the two bolts [S1] on the rear of the front support .
2. Level your TV.
3. Retighten both bolts [S1] to hold TV in place.
UP
UP
