Step
4
03
04
S3
S3
02
04
Secure the TV with Brackets to the Front Support Assembly
HEAVY! You may need
assistance with this step.
HEAVY! You may need
assistance with this step.
4-1. Remove the preassembled bolts [S3] on the TV brackets [04] using screwdriver and
keep them for the use in 4-3.
4-2. Hang the TV with TV brackets [04] to the front support assembly .
4-3. Tighten the bolts [S3] using screwdriver to the brackets to secure the TV to the front
support assembly
UP
UP
UP
UP
01 02 03 04 05 06 07 08 09 10 11 12 13 14
