Perlesmith PSCLF1 - Page 4

Supplied Parts and Hardware for Step 2
Level x1
[Only one bolt size fits your TV]
TV Bolts08
M6 x 15mm x4
M8 x 25mm x4 M8 x 35mm x4 M8 x 50mm x4
M6 x 35mm x4
M6
M8
Note: The bolts are shown in accordance with the actual size
[D1] [D2]
[E1] [E2] [E3]
Arm and Wall Plate 01
x1
x2
05
UP
Wall Plate Template
UP
