Note: The lag screw is shown in accordance with the actual size
Washers
M8
A2
Lag Screws
M8x65mm
x6
x6
A1
Wall
Anchors
x6
A3
These anchors are for
concrete or brick walls
ONLY. DO NOT use them
in drywall or wood studs.
CAUTION!
Supplied Parts and Hardware for Step 3
x2
03
Arm Extension
Socket Wrench
3/8 in.(10mm))
Allen Key
5/32 in.(4mm)
Front Support
02
x1
