Perlesmith PSLFK1 - Step 7: Tilt Adjustment; Step 8: Level Adjustment

If needed, the TV can be leveled +/-3 degrees.
Loosen 2 screws [S1]
S1
Level the TV
To adjust the tilt in both sides,
loosen both tilt levers and move
panel to desired position.
Tighten both tilt levers to hold
desired tilt.
Step 7 Tilt Adjustment
Step 8 Level Adjustment
Tighten 2 screws
S1
TIGHTEN
TIGHTEN
C
！
！
LOOSEN
C
4PCS
± 3°
