Perlesmith PSLLK1 - Page 5

3
Step 1 Check TV Hole Pattern and Select TV Screws
Step 2
Select Spacers (if needed)
Only one screw size fits your TV.
M6 M8
WITH SPACER
3
For Rounded TV
For Flat TV with:
Inset Holes Cable Interference
a
Long Screw
Short Screw
Washer
Washer
Spacer
TV Bracket
TV Bracket
EXTRA
07
07
05
06
05
NO SPACER
b
For Flat TV
Spacer not necessary
SPACE
200 mm ≈ 7 7/8 in.
400 mm ≈ 15 3/4 in.
100 mm ≈ 4 in.
300 mm ≈ 11 3/4 in.
600 mm ≈ 23 6/10 in.
MAX:600mm/23.6 in.
MAX:400mm/16 in.
