Perlesmith PSLLK1 - Page 6

4
Secure the left half of wall plate [01] to the right half of wall plate [02] with
the pre-assembled screw [S].
Assemble the Wall Plate
Tighten
Loosen
DO NOT overtighten.
Tighten only until snug.
Too Short Too Long
Step 3 Secure the TV Brackets to Your TV
Alternate Spacer
Setups
With Spacer
b
07
No Spacer
a
07
07
05
05
06
04
03
Step 4
01
02
S
