Step 6 Secure the TV onto the Wall Plate
[01] and [02]
1. Hang the TV with brackets [03] and [04] onto the wall plate [01] and [02].
2. While pulling and holding both ropes [R] , press the bottom of the TV into
the wall plate [01] and [02] until the latches lock the wall plate [01] and [02],
then release the ropes [R].
WALL
01&02
R
Locking
TV
HEAVY! You may need
assistance with this step.
05 07 09 12
