Awl
Stud Finder
Tape Measure Pencil Drill
7/32'' (5.5mm)
Wood Drill Bit
3/8'' (10mm)
Concrete Drill Bit
1/2'' (13mm)
Socket Wrench
Phillips
Screwdriver
Hammer
OR
(Tools Needed for Wood Stud Installation)
(Tools Needed for Solid Concrete,
Concrete Block and Brick Wall Installation)
Tools Needed (Not lncluded)
Verify Your Wall Construction
If you are not sure of the
wall construction, please
contact our customer
service at
supportus@perlesmith.com.
Solid Concrete
or Concrete Block
CAUTION
DO NOT
install into
drywall alone
Wood Studs
(with Drywall)
Supplied Parts and Hardware
Supplied Parts and Hardware for Step 1
WARNING: This product contains small items that could be a choking
hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. Do not
use damaged or defective parts. lf you require replacement parts, please
contact our customer service at supportus@perlesmith.com.
• PLEASE NOTE: Not all hardware included in this package will be used.
Left TV Bracket
x 1
03
Right TV Bracket
x 1
04
5/16” (8mm)
Wrench
02 05 07 09
To Next Page
