Perlesmith PSLTK1 - Page 4

Right Wall Plate
x 1
01
Left Wall Plate
x 1
02 08
x 1
Level
Supplied Parts and Hardware for Step 2 and 3
Spacers [if needed]
06
[F1]
x 8
L2.5mm
[F2] x 4
L10mm
[F3] x 4
L22mm
NOTE: The spacers shown are actual size.
Washers
05
M4 / M5
[B1] x 4
M6 / M8
[B2] x 4
TV Bolts [Only one size of the bolt fits your TV]
07
NOTE: The bolts shown are actual size.
M6
M4
M8
M4 x 12mm
[C1] x 4
M6 x 15mm
[D1] x 4
M8 x 35mm
[E2] x 4
M8 x 15mm
[E1] x 4
M8 x 50mm
[E3] x 4
M6 x 35mm
[D2] x 4
M4 x 30mm
[C2] x 4
03 05 07 09
