Perlesmith PSTVMC03 - Install TV Plate to Upper Poles

11
Wrench
13/64”
(5mm)
Large Allen Key
[Z-D]
[Z-E]
Back
Front
[Z-J]
07
05
06
Secure the TV plate [06] to the upper poles using the support plate [07], bolts and washers [Z-D],
and nuts [Z-E].
Step 4 Install the TV Plate to Upper Poles
