Perlesmith PSTVMC03 - Secure TV onto TV Plate; Mounting and Tightening TV to Plate

12
HEAVY! You may need
assistance with this step.
Step 5-1 Slightly loosen the preassembled bolts on the brackets.
Step 5-2 Hang the TV with brackets to the TV plate.
Step 5-3 Tighten the bolts on the brackets until the bolts touch the TV plate.
Step 5 Secure the TV onto the TV Plate
13/64”
(5mm)
Large Allen Key
[Z-J]
[Z-J]
[Z-J]
