09
Step 3-1 Adjust the height of the pole assembly.
Step 3-1-1 Loosen the knobs then stretch the upper poles from the lower poles.
Step 3-1-2 Adjust the upper poles to your desired height.
Step 3-1-3 Insert the latches [05-B] into the holes nearest to the connecting part
of upper pole and lower pole, then fasten the knobs [05-A] to fix the two upper
poles in place.
Note：The height of the two upper poles should be the same.
05
05-B
05-A
Step 3 Secure Pole Assembly to Base
To Next Page
