DO NOT over-loosen these four nuts when
adjusting the level angle to prevent the TV
from falling off.
CAUTION!
1. Loosen four tilt nuts [T].
2. Adjust TV to your desired tilt angle.
3. Retighten four tilt nuts [T] secure TV in place.
Tilt
Loosen Tighten
T
T
Step 5 Adjust the Tilt and Level Angle
Wrench
11
