Perlesmith PSXLF01 - Page 4

M8 x 25mm
[E2] x4
M8 x 50mm
[E4] x4
M8 x 15mm
[E1] x4
M8 x 35mm
[E3] x4
[Only one bolt size fits your TV]
TV Bolts
M6 x 15mm
[D1] x4
M6 x 35mm
[D2] x4
M6
M8
Note: The bolts are shown in accordance with the actual size
08
Supplied Parts and Hardware for Step 2
01
x1
Arm Assembly/Wall Plate
Level
x1
Wall Plate Template
05
x1
03
