Perlesmith PSXLF01 - Page 5

Only one bolt size fits your TV.
Step 1 Secure the TV Brackets to TV
Select TV Bolts
M6 M8
Note: The lag screw is shown in accordance with the actual size
Washer
M8
A2
Lag Screw
M8x65mm
x6
x6
A1
Wall
Anchor
x6
A3
These anchors are for
concrete or brick walls
ONLY. DO NOT use them
in drywall or wood studs.
CAUTION!
Supplied Parts and Hardware for Step 3 to Step 4
04
x2
Plastic Cover
02
x1
Front Support
Wrench
x1
04
