Permobil K/C300 Owner’s Manual
57
Design and function, R-net
* Applies only if the wheelchair is fitted with lights.
On/Off
Max. speed/profile
Reduce/increase
Mode
Hazard lights*
Indicators, left*
Horn
Lights*
Indicators, right*
Seat indicator
Battery voltage indicator
Max. speed/profile
indicator
R-Net control panel LED
Function keys
There are a total of 9 function keys on the control panel with LEDs.
On/off key
The on/off key is the switch for the control system’s electronics which, in turn,
supply power to the wheelchair’s motors.
Horn
Pressing the switch produces a sound signal for attracting attention.
Max. speed/choice of profile
These keys normally reduce or increase the wheelchair’s maximum speed. In
special applications, the keys can instead control the choice of driving profile.
m
WARNING
Do not use the on/off key to stop the wheelchair, except in an emergency. You may be thrown out
of the chair, or you may shorten the life of the wheelchair’s drive system.
