PART 8: MAINTENANCE AND SERVICE
PB1319 (CAT. NO. 5296 ) —100— 22-01691 (R02/02)
Drive Axle
(Dana)
Breather Clean or replace. X
Lube Pump (ON HIGHWAY)
Remove the magnetic strainer and inspect for wear particles.
Wash in solvent and dry in air.
X
Lube Pump (OFF HIGH-
WAY)
Remove the magnetic strainer and inspect for wear particles.
Wash in solvent and dry in air.
X
Lube Filter (ON HIGHWAY) Change. X
Lube Filter (OFF HIGH-
WAY)
Change. X
Magnetic drain plug and
breather (ON HIGHWAY)
Clean or replace. X
Magnetic drain plug and
breather (OFF HIGHWAY)
Clean or replace. X
Drive Axle
(Meritor)
Axle Housing Check the “cold” fill level at the differential carrier plug for a pinion
angle of less than 7 degrees, or at the axle bowl plug for a pinion
angle of greater than 7 degrees. Tighten the plug to 35 - 50 Lb. ft.
(47 - 68 N.m.)
X
Axle Housing Visually inspect for damage or leaks. X
SYSTEM COMPONENT MAINTENANCE TASK
Recommended
PM Interval
I ABCDE
