PART 4: CONTROLS AND DISPLAYS
PB1319 (CAT. NO. 5296 ) —15— 22-01691 (R02/02)
Steering Column-Mounted Controls
Turn Signal and Indicator Lights
Turn Signal
The turn signal body is mounted on the left side of the steering column,
below the steering wheel.
• At a right-hand drive station, the turn signal body is mounted on a
stub shaft under the dash behind the steering wheel.
To operate either signal, move the lever in the direction of the turn.
• The left turn indicator light is displayed in the tachometer face.
• The right turn indicator light is displayed in the speedometer face.
NOTE: The ignition key must be turned to ON for the signal/
switch to operate.
WARNING! After you complete a turn, shut the system off
by returning the lever to the “OFF” (center) position. The
switch's lever action is NOT self-canceling. Failure to shut
off a turn signal could confuse other drivers and result in
an injury accident. An indicator light in the instrument
panel will flash until the turn signal is turned off.
02882
