PART 3: GETTING TO YOUR ENGINE
PB1319 (CAT. NO. 5296 ) —11— 22-01691 (R02/02)
Lowering the Cab
1. Place the control valve handle in the “Raise” position and pump
until the locking bar can be removed from the anchor and fastened
in its stored position.
Locking Bar In Stored Position
.
2. Place the control valve handle in the “Lower” position. The cab
should settle down on the rear mounts.
Upper and Lower Rear Cab Mount
3. Allow at least 20 seconds after the cab touches down for the full
spring force to develop in the latch hooks in the rear mounts.
4. Remove the pump handle and store in the cab.
5. Visually inspect the cab latch hooks to ensure they are closed.
6. Ensure that the control valve handle is in the “Lower” position
when operating the vehicle.
CAUTION: Do not try to pump the cab down or hold it
down with hydraulic force. If you do, cab damage will
occur.
02878
02879
