OPERATINGTHEBRAKESYSTEM
OPERATINGTHE
BRAKESYSTEM
Introduction
Thisvehicle’sbrakesystemfunctions
withtheuseofcompressedair
generatedfromtheengine’sair
compressor.Thecompressedairis
storedinvariousairtankstoensure
thatairpressureisavailablewhenever
thedriverneedsit.
Compressedairisdeliveredtothe
brakesystemthroughthevalveat
thebrakepedalandiscontrolled
withvariousvalvesandbraking
circuits.Thebrakesystemisdesigned
withseparatefront,rearand(when
applicable)trailercircuitssothatifone
circuitiscompromisedandlosesair,
theothercircuitswillnotbeaffected.
Safetyvalvesineachcircuitwillprotect
theothercircuitsintheeventthata
circuitlosesair.
Theaircompressorontheenginewill
typicallyprovide100-130psi(690-896
kPa)totheairtanks.Thevehicle
isalsodesignedwithanairdryer,
whichremovesmoisturefromthe
compressedairinordertoprotectall
componentsintheairsystem.
Thebrakesystemmaybefurther
enhancedbyadditionaldevices
suchasbrakeproportioningvalves,
Anti-lockbrakingsystemsorsensors
designedtoletyouknowifyourbrake
padsneedtobeserviced.
Certainconditionsmayresultinthe
brakesurfacesgettingwet.Brake
surfacesthatarewetdonotperform
aswellaswhentheyaredry.There
maybesituationswherewetbrake
surfacescannotbeavoided.Insuch
situationsapplythebrakeswhilein
motion,todrythebrakesurfaces.
Certainconditionsmayresultinyour
brakesurfacesbecomingoverheated
(above800°For427°C).Overheated
brakeswilldamageliningsanddrum
surfaces,ultimatelydecreasingbraking
performance.RefertoRetarderson
page4-32andDescendingaGrade
onpage4-45toavoidoverheatingthe
brakes.
Thisvehiclemaybeequippedwith
ananti-lockbrakingsystem(ABS).
ThisABSreducesthepossibilityof
wheellock-up.Ifawheelisabout
tolockduringbraking,theABSwill
automaticallyadjustairpressuretothe
brakechambersontheappropriate
wheel(s)topreventwheellock-up.The
ABSisautomaticallyturnedonwhen
theignitionswitchisturnedon.
(03/17)Y53-6076-1B14-21
