GuidetotheWarning
Symbols
Thewarninglightsandaudiblealarm
mayindicateasystemmalfunction.
Checkthelightsfrequently,and
respondproperlyassoonasyousee
onegoon.Theselightscouldsave
youfromaseriousaccident.
Whenmultiplewarningiconsare
shownontheinstrumentcluster,
theywillappearatrstandthen
minimize.Whenminimizedtheywill
berepresentedintheactivewarnings
areaofthedisplay(seeWarning
Light/IndicatorSymbolsonpage3-16
fordetails).Atrianglerepresentsa
warningregisteredandadiamond
representsacheckmessage.
WARNING!
Donotignoreawarninglightor
audiblealarm.Thesesignalstell
yousomethingiswrongwithyour
vehicle.Itcouldbeafailureinanim-
portantsystem,suchasthebrakes,
whichcouldleadtoanaccident
causingdeathorinjury.Havethe
appropriatesystemcheckedimme-
diately.
Checkmessagesareprovidedtogive
theoperatoradditionalinformation
regardingsystemsthatrequire
attentionduetoasystemmalfunction
and/oroperatingconditionsthatmay
hindersafeandproperperformance
forthevehicle.Thesystemwillemit
achimetoalerttheoperatorthata
messageisappearingonthecluster.
Somemessagescanbemanagedby
theoperatorwhileothersmayrequire
anauthorizeddealerrepair.
ThefollowingisalistofWarning
Light/IndicatorSymbolsthatappearin
theinstrumentcluster.
•theSymbolName
•theappearanceoftheSymbol
•theSymbolColorwhenitis
illuminated
•whetherthesymbolisstandard
(Std)oroptional(Opt)
•whetherthesymbolhasan
associatedcheckmessage
•thePageNumberreferencefor
additionalinformation
Symbolsarelistedbymajorcomponent
sections.
Example:Engine,andthenin
alphabeticalorder.
(03/17)Y53-6076-1B13-15
