INSTRUMENTPANEL
InstrumentCluster
Description
InstrumentSystemSelf-Test
Whentheignitionswitchisturned
ontheinstrumentationsystemwill
undergoaSelf-T est.Thistestwill
verifytheoperationofthegaugesand
warnings.
DuringtheInstrumentationSystem
Self-Test,multiplewarningiconswill
bedisplayedinasequence.Thetotal
sequenceshouldonlytakenomore
than10secondstocomplete.
RefertoWarningLight/Indicator
Symbolsonpage3-16forinformation
oneachsymbol.
Completingthissequencewillindicate
asuccessfulSelf-T est.Haveyour
instrumentationsystemcheckedbya
qualiedservicetechnicianifdoesnot
successfullycomplete.
AudibleAlarm
Theaudiblealarmwillsoundduring
theInstrumentationSystemSelf-Test.
Theaudiblealarmwillalsosoundin
conjunctionwithmostwarninglights.
Theseeventsincludebutarenot
limitedtoheadlighton,fthwheel,stop
engine,primary/secondaryair,and
driverdooropenwarnings.
OptionalIcons
Additionaliconsmaybeoperational
dependingonindividualvehicle
specications.Thesewillbeincluded
intheInstrumentSystemSelf-T est.
NOTE
Someoptionallightsmayillumi-
nateeventhoughyourvehicleisnot
equippedwiththatparticularfea-
ture.
