Connecting Machine To Power Source
Connect the machine to a power source as
illustrated. (1)
This appliance is equipped with a polarized
plug which must be used with the
appropriate polarized outlet. (2)
Unplug power cord when machine is not
in use.
The foot control pedal regulates the sewing
speed. (3)
Consult a qualified electrician if in doubt
of how to connect machine to power
source. Unplug power cord when
machine is not in use.
The foot control must be used with the
appliance by KD-1902, FC-1902 (110-
120V area)/ KD-2902, FC-2902D (220-
240V area)/ 4C-316B (110-125V area)/
4C-326G (230V area).
Press main switch (A) to " l " for power and
light.
a. Polarized attachment plug
b. Conductor intended to be grounded
Attention:
Foot control
Attention:
Sewing light
a
b
3
2
31
Machine Basics
When sewing several layers or thick fabrics,
the presser foot can be raised
for easy positioning of the work. (A)
to a higher
position
Two Step Presser Foot Lifter
