Automatic Needle Threader
- Raise the needle to its highest position.
- Press lever (A) down as far as it will go.
- The threader automatically swings to the
threading position (B).
- Pass thread around thread guide (C).
- Pass the thread in front of the needle
around the hook (D) from bottom to top.
- Release lever (A).
- Pull the thread through the needle eye.
Attention:
Turn power switch to off ("O")!
Threading the Machine
Raising the Bobbin Thread
Hold the upper thread with the left hand.
Turn the handwheel (1) towards you
(counterclockwise) lowering, then raising
needle.
If it is difficult to raise the bobbin thread,
check to make sure the thread is not
trapped by the hinged cover or the
Removable Extension Table.
Gently pull on the upper thread to bring the
bobbin thread up through the needle plate
hole. (2)
Lay both threads to the back under the
presser foot. (3)
Note:
1
2
3
36
GB/IE
