Controls
7 - 4
7
.07
Key on machine head
●
By operating key
1
during sewing, the
machines switches to reverse sewing
(only on machines with backtacking
mechanism –911/93).
7
.08
Switch for thread wiper –909/93
●
The thread wiper can be switched on or
off by pressing switch
1
.
Position
l
:
unit is switched on
Position
0
:
unit is switched off
79-006
79-005
Fig. 7 - 07
1
1
Fig. 7 - 08
16
18
