Pfaff 1183 - Needle to Needle Hole Centre (on PFAFF 1051 and PFAFF 1181)

Adjustment
11 - 12
11.05.10 Needle to needle hole centre (on PFAFF 1051 and PFAFF 1181)
Requirement
The needle must enter excatly in the centre of the needle hole.
● Set stitch length "0".
● Set the needle in the needle hole by turning the balance wheel
● Turn needle bar frame 1 (screws 2 and 3) according to Requirement.
Fig. 11 - 11
1
3
2
