Pfaff 1183 - Limiting the Stitch Length

Adjustment
11 - 21
11.05.19 Limiting the stitch length
The maximum stitch length which can be selected can be limited mechanically.
When using Version A and B part sets, the maximum adjustable stitch length
must not be larger than 4.5 mm!
● Set the desired maximum stitch length with regulator disk 1.
● Move crank 2 (screws 3) down against stop 4.
2
4
3
Fig. 11 - 20
1
