Pfaff 1425 - Knife Cutting Position

11 - 44
Adjustment
11.07.04 Knife cutting position
Requirement
When the knife is in its cutting position, there shold be a clearance of 34 mm between the
front edge of the knife and the front edge of the position stop 3.
● Adjust position stop 1 (screws 2) according to the requirement.
58.043
2
1
Fig. 11 - 41
34 mm
3
