Pfaff 480 Series User Manual

Adjustment
2.11 Positioner
Requirements
1. When sewing is interrupted, the machine should position itself 4 to 5 mm after the
BDC of the needle bar.
2. After trimming, the machine should position itself at the TDC of the take-up lever.
3. When pressing the pedal backwards, the plunger of the cylinder should extend when
the needle bar is 20 - 22 mm after the BDC.
● For adjusting the stop positions, please see the instruction manual of the motor and
chapter 2.13 Parameter settings.
2 - 10
