Adjustment
7 701 I = Positioner adjustment with
hand wheel
II = Positioner adjustment with
buttons „+“ and „-“
706 Trimming signal for shifting the
catcher forward at end of seam
752 Stopping time at TDC (ms) of
take-up lever for reverse
movement of catcher at start of
seam
786 Trimming signal to move catcher
backwards at start of seam
(when changing the standard
value, make sure that parameter
701 is set to II)
787 Signal for stitch condensation at
start of seam
788 Signal for stitch condensation at
end of seam
For further information please refer to the motor manufacturer’s instruction
manual.
II
1190 - 239
0 - 640
0
2 - 13
Group Parameter Meaning Adjustment range Standard value
140 - 160
150
0 - 239
217
2240 - 239
