Adjustment
11 - 62
● When the cutter is moving forward, the thread trapper must first trap and hold the threads
reliably on the cutter (if necessary adjust the thread trapper as required after loosening
retaining screw 4).
● As the process continues, both the bobbin thread and the part of the thread loop closest to
the cutter, which is held by the catching lug must be cut perfectly.
● If the threads are not cut at all or not cut fully, check the chapter 11.07.14 Cutter driving
rod again.
● Carry out a check according to the requirement.
